#RS485 OPTICAL ISOLATOR SERIAL#
110/240VAC to 12VDC power supply adapter is includedįor alternative RS232 isolation solutions please see our full selection of serial converters and isolators.
#RS485 OPTICAL ISOLATOR FREE#
Power supply and serial cables includedĮxternally powered by 9 - 18 VDC power supply. ATNEDCVH RS232 RS485 to 4 Ports RS485 Repeater Optical Isolator Industrial Grade, RS485 hub 4 in 1 Out Signal Amplifier Anti-Interference (Blue) 45 99 Get it as soon as Fri, Feb 4 FREE Shipping by Amazon Only 10 left in stock - order soon.Two 4-feet M/F Serial cables and one 110/240VAC to 12VDC power supply adapter is included with each isolator.Īn all-round solid serial RS232 isolator ideal for most industrial environments and applications. Standard DB9 connectors allows easy connection of any standard DB9 serial cable. The power supply is galvanic isolated from the rest of the isolator which ensures noise or surges from the power supply enters the isolator this gives an additional level of isolation.īaud rates of 300 to 115200bps and indication LED lights for TX, RX and Power makes this isolator easy to use and compatible with most serial devices. This isolator must be powered by an external 9 to 18 VDC power supply. High-speed 6N137 opto-couplers from Fairchild Semiconductor is what ensures protection and high performance in this isolator. Static electricity and other high voltage surges is protected against for up to 15KV. Optical isolation for up to 2500 Vrms and continuous 500VDC ensures effective protection against voltage spikes and surges and ground loops.
RS-485 supports 32-point polling environment (128-point could be customized)ġ2~36VDC, 3-pin 5.What we have here is a high-speed industrial grade RS232 optical isolator which provides isolation for all 8 communication wires. RS-485 adopts automatic data flow control technology which can detect and control data transmission direction automatically RS-485/422 serial port, adopt 5-pin 5.08mm pitch terminal blocks RS-485/422 repeater (two modes cannot operate simultaneously) Support DIN-Rail or wall mount installation Ĭompliant with EIA RS-232C, RS-485/RS-422 standards
#RS485 OPTICAL ISOLATOR DRIVERS#
Supports high-speed serial data rates: 300 to 115200bps ĭata direction auto-turnaround, no software drivers or flow control is required Support RS-485/422 repeater function, communication distance up to 3Km(9600bps) īuilt-in 1500W surge protection, 15kV static protection and circuit protection
Support bidirectional data conversion between 1-port RS-232 and 1-prot RS-485/422
MW1040-I-R supports serial data rates up to 115,200bps, auto-sensing and self-adjusting, no DIP switch or jumpers are required, which widely used in electric power system, industrial automation control, IC card charging system and measuring instrument, distributed data acquisition and other occasions. Serial ports are equipped with 1500W surge protection, 15kV electrostatic protection and 3kV photoelectric isolation protection, effectively avoid damage caused by lightning strikes, surges and other factors.
RS-485/422 supports serial port self-adaption technology that can identify RS-485/422 serial port automatically without the need of setting the switch. The MW1040-I-R is an industrial-grade RS-485/RS-422 repeater and converter, which can convert the RS-485/RS-422 signal in high rate with 3000V optical isolation, It provides 1-port RS-232 and 2-port RS-485/422.
